SVABITE
Chemical Formula: Ca5(AsO4)3(F,OH)
Familly: Phosphates, Arseniates, Vanadates
Status: IMA-GP
Crystal System: Hexagonal
Mineral for Display: Yes
Luminescence:
UV Type |
Main color |
Intensity |
Observation Frequency |
|
| | | |
Short Waves (254 nm): | Orange | Strong | Always | | | | |
Short Waves Pictures (254nm)
Svabite SW,
Langban, Filipstad, Varmland Province, Sweden ;
Photo & Col. © G. Barmarin
Galerie de photos:
The directory does not exist...
To the gallery ( images in the gallery)
Phosphorescence (in the common meaning of the term) seen by naked eye:
No Data
Comments:
Associated with dull red fluorescing tilasite in Langban.
Main Activator(s) and spectrum:
Most Common Activator: Mn2+
Other activators: Nd3+ ,
Peaks in the spectrum (nm):
Mn2+ repl. Ca2+ : band peaking at 585 - 612nm
Nd3+ : 874nm (exc. 780nm)
No spectrum for the moment
Comments on activators and spectra:
Svabite was studied by steady-state luminescence spectroscopy and luminescence of Mn2+ was found (Gorobets and Rogojine 2001).
Excitation by CW laser with 532 and 780 nm revealed band of Mn2+ and narrow luminescence lines of evidently Nd3+
Best Locality for luminescence(*):
- Langban, Filipstad, Varmland Province, Sweden ;
- Ultevis, Lappland, Sweden ;
- Franklin, New Jersey, USA ;
- A skarn at Solongo, Buriat Republic, Russia ;
- Jakobsberg Mine, Jakobsberg ore field, Nordmark district, Filipstad, Värmland, Sweden (Svabite pseudomorphose after Tilasite);
(*)Data are not exhaustive and are limited to the most important localities for fluorescence
Bibliographical Reference for luminescence:
- The Henkel Glossary of Fluorescent Minerals, Dr. Gerhard Henkel, Published by the FMS, 1989 ,
- Fluorescence: Gems and Minerals Under Ultraviolet Light, Manuel Robbins, 1994, Geoscience Press, ISBN 0-945005-13-X ,
- The World of Fluorescent Minerals, Stuart Schneider, Schiffer Publishing, 2006, ISBN 0-7643-2544-2 ,
- Luminescence Spectroscopy of Minerals and Materials, M. Gaft, R. Reisfeld, G. Panczer, Springer Editor, ISBN: 10 3-540-21918-8 ,
- Luminescent Spectra of Minerals, Boris S. Gorobets and Alexandre A. Rogojine, Moscow, 2002 ,
